iPECS UCP
Feature Description and Operation Manual Issue 1.3
165
2.52 LBC (Loud Bell Control)
Description
The iPECS hardware is equipped with relays that activate External Control Contacts. Each
contact is assigned to one of several functions including a Loud Bell Control. If used as a
Loud Bell Control, the contact will activate when:
External Page is accessed
Assigned Station receives ring in Day Ring mode (LBC)
UNA (Universal Night Answer) outside line receives a call while in the Night or
Timed Ring mode.
Operation
System
Conditions
Operation of the relays is automatic when defined.
1. The UCP100 supports one contact and in UCP600/2400 four contacts are
available, each appearing in the Miscellaneous connections of the iPECS UCP
module.
2. When assigned to activate as a Loud Bell Control, outside Line ring, transfers, and
tone ring Intercom calls to the assigned station will activate the contacts.
3. The contacts are rated at 1 amp, 24 VDC.
4. While in the Night or Timed Ring mode, the LBC function is not activated by ringing
at the assigned station. If the system is in the Night or Timed ring mode with
External Night Ring enabled, an incoming call on an outside Line assigned with
UNA will activate the contact. This permits operation of an external night ring
device.
Programming
