2.69 Registration & Fractional Module Tables
Description
Normally, local iPECS devices can register with the system only when the “Registration
Switch”, 3rd Dip switch on the UCP module, is ON. In this state, the system will allow any
local iPECS device to register, providing a convenient “plug & play” initial installation. After
initial installation, the Registration Switch is placed in the OFF position, disabling registration
of additional local devices.
To eliminate the potential for unintended device registration, particularly where multiple
systems exist on the same LAN, the system can be programmed to allow local device
registration employing MAC addresses. Using the defined MAC address registration, the
system allows a device with a matching MAC address to register regardless of the
Registration Switch position.
Three tables are provided to enter MAC addresses. The System & Device IP Plan allows
entry of two MAC address ranges. Any device with a MAC address in either of the ranges will
be permitted to register with the system.
The second is the Registration Table. This Table permits entry of five MAC addresses and
the number of channels to be registered for each device. Entering the MAC address permits
the device to register with the system regardless of the Registration Switch position. The
number of channels available to the device is limited to the number of channels entered in the
Table. This function is commonly used to limit the number of channels available over an
E1/T1 or PRI ISDN circuit (Fractional T1 line).
The third is Device Login  Remote Device Registration that allows entry of the MAC
address of a remote phone or gateway Module as well as the Nation code and Zone. During
registration, the system will compare the MAC address received from the remote device and,
if matched, will permit registration of the device. Once the device is registered, the data for
the device is placed in the appropriate locations and the data is removed from the Remote
Device Registration Table.
Operation
Conditions
Operation of registration is automatic based on the system database and Registration
Switch position.
Programming
SYSTEM ID
&NUMBERING PLANS
System& Device IP Plan First MAC Range, Second MAC
Range
TABLES DATA
Registration Table
