iPECS UCP
Feature Description and Operation Manual Issue 1.3
6
2.3 Alarm Signal/Door Bell
Description
The system can be configured to recognize the status of an external contact (normally open
or closed). The system will signal assigned iPECS IP and LDP Phones when the contact
activates. This capability is commonly employed to provide remote Alarm or Door Bell signals.
Assigned stations receive the Alarm Signal, either a single tone burst repeated at 1-
minuteintervals or a continuous tone. The Alarm Signal may be terminated at the phone by
dialing the Alarm Reset code or, if assigned, pressing the {ALARM RESET} button. To rearm
the Alarm function, the alarm condition must be cleared after the Alarm signal is reset.
When used as a Door Bell, assigned iPECS IP and LDP Phones receive a single tone burst
each time the external contact is activated and no reset is required.
Operation
System
iPECS IP & LDP Phones
At detection of contact operation, the Alarm/Door Bell signal is sent to assigned stations.
[TRANS/PGM] + {FLEX} + “565” + [HOLD/SAVE]
To assign a Flex button as an {ALARM RESET} button to terminate the Alarm Signal
1. Dial the Flex Numbering Plan code “565”, confirmation tone is received and the
Alarm Signal is terminated. If the alarm condition is cleared, the system will
automatically rearm the alarm monitoring.
To terminate an Alarm Signal, while idle
Or,
1. Press the {ALARM RESET} button.
Conditions
1. The Alarm contacts must be “dry”, no voltage or current source connected.
2. Only iPECS IP and LDP Phones may be assigned to receive Alarm/Door Bell
signals.
3. The LCD of phones assigned to receive Alarm/Door Bell signals will show “ALARM”
or “DOOR BELL” as appropriate.
4. The Alarm Reset code is also employed to terminate alarm signals from digital and
IP trunks as well as Cabinet alarms.
Programming
SYSTEM DATA Alarm Attributes Alarm Enable, Alarm Contact Type,
Alarm/Doorbell Mode, Alarm Signal Mode
