6.7 Cabinet Alarm
Description
The Cabinet Alarm alerts the Attendant of a fault in the fans or power supplies in a cabinet.
The alarm notification displays the cabinet number. The cause of the fault, cabinet fan, PSU
or PSU fan is shown on the Cabinet Attributes Web Admin page. The alert may be
terminated at the Attendant’s phone by dialing the Alarm Reset code or, if assigned, pressing
the {ALARM RESET} button.
Operation
CABINET XXX STS FAULT
When an alarm condition occurs, the Attendant phone will display
System Attendant
[TRANS/PGM] + {FLEX} + “565” + [HOLD/SAVE]
To assign a Flex button as an {ALARM RESET} button to terminate the Alarm Signal
1. Dial the Alarm Reset code, “565”, confirmation tone is received and the display
returns to normal.
To terminate an Alarm Signal while idle
Or,
Press the {ALARM RESET} button.
Conditions
1. The PSU serial port must be connected to the gateway or UCP Module identified
in System Data Cabinet Attribute.
2. If the serial monitoring cable of the PSU is connected to a WTIM, refer to the
Description and Installation Manual for proper DIP-switch settings; DIP-switch 3 of
the WTIM must be set to the OFF position.
3. The notification identifies the cause of the alarm as FAN1 or FAN2 for the Main
Cabinet fans, PSU1 or PSU2 for a power supply fault or PSU1 FAN or PSU2 FAN.
Programming
