iPECS UCP
Feature Description and Operation Manual Issue 1.3
173
Dial a Park code to Park the call.
Or,
Dial a Page zone to place an Internal/External or All Call page within the iPECS
system.
Or,
Dial a Conference Room to transfer the external party to a Conference Room.
Note
The mobile may reconnect to the call by dialing “#”.
1. The mobile phone of MEX is on MEX call.
To move from mobile phone to desktop phone
2. Press {my station number} flexible button in desktop phone.
3. The user can do the MEX call with the desktop phone.
1. The desktop phone of MEX is on MEX call.
To move from desktop phone to mobile phone
2. Press {my station number} flexible button in desktop phone.
3. Then, the mobile phone is ringing.
4. The desktop phone ends the call.
5. When the user answers with the mobile phone, the user can do the MEX call
with the mobile phone.
System
Conditions
Incoming calls are sent to the active mobile phone automatically.
1. When the mobile phone places an external call through iPECS, the CLI of the
corresponding station is used.
2. The Mobile Extension features is supported on analog CO Lines however, timers
must be set to compensate for answer and disconnect supervision, which is not
reliable on these Line types.
3. Message Wait and Callback cannot be activated to a mobile phone.
4. The Mobile Extension feature is not supported over a distributed networked
environment.
5. When an incoming call is received, the system will access an outside line and
place a call to the mobile phone. Thus, an outside line must be available for the
system to notify the mobile user of the incoming call.
6. Hold and Transfer Recalls to the mobile phone are sent to mobile phone and the
associated station.
7. ACD, Circular and Terminal Hunt Group calls can be routed to the active Mobile
Extension.
8. To move between mobile and desk phone is applied to only keysets with flexible
buttons.
