iPECS UCP
Feature Description and Operation Manual Issue 1.3
293
4. Replace the handset, to return to idle.
3. Dial “556”, the Call Back code.
To queue for a page when busy tone is received
4. Replace the handset returning to idle.
Conditions
1. Stations, which are denied access to paging, will receive error tone when any
Page Access code is dialed.
2. When calling a busy Page Zone, you will receive busy tone. You may use callback
to queue for the Page Zone. Note that All Call Page is busy when any Page Zone
is busy.
3. DTMF signals from stations are transmitted through the systems External Page
port after access.
4. If an iPECS IP or LDP Phone user attempts to page using the speakerphone, pre-
selection will be activated and the display shows ‘Lift Handset for Page when ‘Lift
Handset for Page’ is ON’.
If ‘Lift Handset for Page’ is OFF then user can make page on speakerphone
without lift handset.
5. Stations in DND or busy will not receive Page announcements.
6. Stations that are not included in any Internal Page Zone, will not receive any page,
including All Call.
7. For external paging, an external amplifier and speaker(s) are required.
8. The systems External Control Contacts may be assigned to activate when External
Page is accessed. The contact can be used to activate the External page
equipment.
9. A station is permitted only one Page Zone queue request at a time. If a station
attempts another Page Zone queue, only the later queue request is honored.
10. When a busy Page Zone becomes idle, the system will select the oldest page
queue, and signal the appropriate station. The signaled station will receive an
audible ring indicating the queue callback. The audible ringing will be a distinctive
signal. The All Page Zone, while signaling a queued station, is considered busy. In
addition, the All Page Zone is considered busy when any page zone is active.
11. The queue recall is always in the tone ring mode regardless of the station’s ICM
signaling mode. The recall signals the station for 15 seconds, after which, the
queue is canceled and the next station in the queue is signaled.
12. If the waiting station is busy, and the Page zone becomes available the next idle
station in the Page Queue list is signaled and the busy waiting station is placed at
the bottom of Page Queue list. If there is no other available queued station in the
Page Queue, the Page Queue for the busy station is canceled.
13. When the waiting station goes to idle, and both a “Page Queue” and “CO Call back
Queue” exist, the Page Queue is given priority.
Programming
STATION DATA Common Attributes Page Access
