iPECS UCP
Feature Description and Operation Manual Issue 1.3
321
iPECS IP & LDP Phones
[TRANS/PGM]+{FLEX}+[TRANS/PGM]+“85”+“#”’+MSN digits+[HOLD/SAVE]
To program an {MSN} button
Conditions
1. If the Called Party Number from the ISDN does not match an MSN Table entry, the
received digits are treated as defined for DID calls to determine an index to the
Flexible DID Table.
2. The MSN Table employs the outside Line number entry as a quick look-up
reference. If the Line number is programmed in the MSN Table, then only those
entries with the Line number are searched, otherwise the entire MSN Table is
searched for a match to the Called Party Number.
3. When assigning an {MSN} button the “MSN digits” should match one of the MSN
Table entries. To assign an MSN button on the phone, the MSN number must exist
in the system MSN Table.
4. An MSN loop button is overwritten by an individual CO line button, if it is exist. On
the other hand, an MSN loop button is not overwritten by CO Group button.
5. Multiple duplicate {MSN LOOP}buttons can be assigned on an iPECS IP or LDP
Phone.
6. If enabled in SMDR, the MSN number is output as the Account code for outgoing
calls employing an MSN button.
7. MSN Call Wait can be assigned to deliver the call to a busy station. If not assigned,
the call is routed using the DID/DISA Destination or is disconnected.
Programming
STATION DATA Common Attributes MSN Wait
Flexible Buttons
