7. Handset Menu System
7-11
Chapter7 Handset Menu System
Fig. 7.1.5c Each status display screen of
Unit Info(4/4)
6. MDM status display screen
OK
Unit Info menu screen
1 Status
2 SMS
5 Unit Info
6 ID
1 Version
2 Mainte No.
3 Class
4 ADE
5 BDE
6 MDM
7 Active SIM
8 Remote Mnt
7. Active SIM display screen
Active SIM:
Primary
8. Remote Mnt Status display screen
Remote Mnt:
Idle
OK
OK
Using SIM Card
(Primary / Secondary)
Status of Remote Maintenance
(Idle / Active)
Carrier / Noise ratio
….Receiving Channel Index
…. Receiving Bearer
.Receiving frequency offset
.BDE Temperature
.HAL Acquisition Status
.L1 Hardware Error
(Normally 0 is displayed)
.Alarm bit
C/No:
64.25
RX Ch Index:
17825
Rx Bearer:
1
RX Offset:
+0
BDE Temp:
+44
HAL Acq Sts:
3
LI HW Err:
0
A:
0
