Lantronix SISPM1040-xxxx-L3 Web User Guide
33856 Rev. A https://www.lantronix.com/ 104
LeaveAll-time is a value in the range of 1000-5000cs, i.e. in units of one hundredth of a second. The default is
1000cs.
Max VLANs: When GVRP is enabled, a maximum number of VLANs supported by GVRP is specified. By default,
this number is 20. This number can only be changed when GVRP is turned off.
GVRP Port Configuration: This section lets you enable or disable a port for GVRP operation. This configuration
can be performed either before or after GVRP is configured globally - the protocol operation will be the same.
Port: The logical port that is to be configured.
Mode: Mode can be either 'Disabled' or 'GVRP enabled'. These values turn the GVRP feature off or on
respectively for the port in question.
Buttons
Apply: Click to save changes.
Reset: Click to undo any changes made locally and revert to previously saved values.
