Sample Configuration
Major Ring and Sub Ring : 4 Switches
Major : SW#1, SW#2, SW#4; Sub : SW#2, SW#3, SW#4
VLANs APS Data
10,20 5
RPL Mode Major Sub Major Sub Major Sub
Owner Owner Neighbor Neighbor None None
Switch Switch Switch Switch Switch Switch
#1 #3 #2 #2 #4 #4
