IP Subnet-based VLAN
The IP subnet to VLAN ID mappings can be configured here. This page allows adding, updating and deleting IP
subnet to VLAN ID mapping entries and assigning them to different ports. The maximum possible IP subnet to
VLAN ID mappings is 128.
Delete: To delete a mapping, click this button.
IP Address: Indicates the subnet's IP address (Any of the subnet's host addresses can be also provided here, the
application will convert it automatically).
Mask Length: Indicates the subnet's mask length.
VLAN ID: Indicates the VLAN ID the subnet will be mapped to. IP Subnet to VLAN ID is a unique matching.
Port Members: A row of check boxes for each port is displayed for each IP subnet to VLAN ID mapping entry.
To include a port in a mapping, simply check the box. To remove or exclude the port from the mapping, make
sure the box is unchecked. By default, no ports are members and all boxes are unchecked.
Buttons
Add New Entry: Click to add a new IP subnet to VLAN ID mapping entry. An empty row is added to the table,
and the mapping can be configured as needed. Any IP address/mask can be configured for the mapping. Valid
values for the VLAN ID are 1 to 4095.
The IP subnet to VLAN ID mapping entry is enabled when you click on "Save". The Reset button can be used to
undo the addition of new mappings.
Apply: Click to save changes.
Reset: Click to undo any changes made locally and revert to previously saved values.
Auto-refresh: Check this box to refresh the page automatically every 3 seconds.
Refresh: Refreshes the displayed table.
Messages: No multicast or broadcast address allowed
