Lantronix SISPM1040-xxxx-L3 Web User Guide
33856 Rev. A https://www.lantronix.com/ 391
OSPFv3 > Configuration > Area Range
This page displays the OSPF6 area range configuration table. It is used to summarize the intra area paths from a
specific address range in one summary-LSA (Type-0x2003) and advertised to other areas or configure the
address range status as 'DoNotAdvertise' which the summary-LSA (Type-0x2003) is suppressed.
The area range configuration is used for Area Border Routers (ABRs) and only router-LSAs (Type-0x2001) and
network-LSAs (Type-0x2002) can be summarized.
The AS-external-LSAs (Type-0x4005) cannot be summarized because the scope is OSPF6 autonomous system
(AS).
The AS-external-LSAs (Type-0x4007) cannot be summarized because the feature is not supported yet.
Delete: Check to delete the entry. It will be deleted during the next save.
Area ID: The OSPF6 area ID.
Network Address: IPv6 network address.
Mask Length: IPv6 network mask length.
Advertise: When the value is true, it summarizes intra area paths from the address range in one Inter-Area Prefix
LSA(Type-0x2003) and advertised to other areas. Otherwise, the intra area paths from the address range are not
advertised to other areas.
Cost: Cost (or metric) for this summary route. It can only be configured when 'Specific' is selected.
Auto: Sets the cost value is set to 0 automatically and isn't allowed to be configured (default).
Specific: Lets you manually set the cost (or metric). The allowed range is 0 – 16777215.
Buttons
Add New Entry: Click to add a new entry to the table.
Apply: Click to save changes.
Reset: Click to undo any changes made locally and revert to previously saved values.
Messages:
The input value Network address (0::0) is not a valid IPv6 address.
