Lantronix SISPM1040-xxxx-L3 Web User Guide
33856 Rev. A https://www.lantronix.com/ 117
Port Storm Policer Configuration: There is a storm policer for known and unknown Unicast Frames, known and
unknown Broadcast Frames, and Unknown (flooded) unicast, multicast and broadcast Frames.
Port: The port number for which the configuration below applies.
Enable: Enable or disable the storm policer for this switch port.
Rate: Controls the rate for the port storm policer. Valid values are 10-13128147 when "Unit" is fps or kbps, and
1-13128 when "Unit" is kfps or Mbps. The rate is internally rounded up to the nearest value supported by the port
storm policer. Supported rates are divisible by 10 fps or 25 kbps.
Unit: Controls the unit of measure for the port storm policer rate as fps, kfps, kbps or Mbps.
Buttons
Apply: Click to save changes.
Reset: Click to undo any changes made locally and revert to previously saved values.
