Lantronix SISPM1040-xxxx-L3 Web User Guide
33856 Rev. A https://www.lantronix.com/ 132
Map ID: Indicates the Map (unique) ID. Range is 0 to 511.
Key-Type: Indicates the Key Type that will be used to filter the map rules when applying the map. As mentioned
above, Map Rules can have various keys, and this is to make a select set of them. Possible Key types are:
CoS ID: Use classified COS ID as key. Table width: 1.
CoS ID - DPL: Use classified COS ID and DPL as key. Table width: 4.
DSCP: Use classified DSCP as key. Table width: 8.
DSCP - DPL: Use classified DSCP and DPL as key. Table width: 32.
Action-Type: Indicates the type of action that will be used to filter the map rules when applying the map.
As mentioned above, map rules can have various actions available, and this is to make a select set of them.
Possible Action types are:
PCP: Priority Code Point.
DEI: Drop Eligible Indicator.
DSCP: Differentiated Services Code Point.
Modification Buttons: It is possible to modify each map (or add new maps) in the table using these buttons:
Edit: Edits the map.
Delete: Deletes the map.
Add: Adds a new map in the table. Note: this button can also be used to overwrite an existing map, so use
care on the Map ID.
Buttons
Auto-refresh: Check this box to refresh the page automatically every 3 seconds.
Refresh: Click to refresh the page.
Remove All: Click to clear all table entries.
QoS Map Rules Configuration
Maps have multiple rules inside them, and this page allows to view and configure the key and action filters that
will be used when searching through the rules. To see and configure the set of rules for each map click on the
Map ID (link) for each map. (Note: not the Edit button.)
