Lantronix SISPM1040-xxxx-L3 Web User Guide
33856 Rev. A https://www.lantronix.com/ 153
Topology Flag: The current state of the Topology Change Flag of this Bridge instance.
Topology Change Count: The number of times where the topology change flag has been set (during a one-
second interval).
Topology Change Last: The time passed since the Topology Flag was last set.
CIST Ports & Aggregations State
Port: The switch port number of the logical STP port.
Port ID: The port id as used by the STP protocol. This is the priority part and the logical port index of the bridge
port.
Role: The current STP port role. The port role can be one of the following values: AlternatePort, BackupPort,
RootPort, and DesignatedPort.
State: The current STP port state. The port state can be one of the following values: Discarding Learning
Forwarding.
Path Cost: The current STP port path cost. This will either be a value computed from the Auto setting, or any
explicitly configured value.
Edge: The current STP port (operational) Edge Flag. An Edge Port is a switch port to which no Bridges are
attached. The flag may be automatically computed or explicitly configured. Each Edge Port transits directly to the
Forwarding Port State, since there is no possibility of it participating in a loop.
Point-to-Point: The current STP port point-to-point flag. A point-to-point port connects to a non-shared LAN
media. The flag may be automatically computed or explicitly configured. The point-to-point properties of a port
affect how fast it can transit to STP state.
Uptime: The time since the bridge port was last initialized.
Buttons
Auto-refresh: Check this box to refresh the page automatically every 3 seconds
Refresh: Click to refresh the page immediately.
.
