Lantronix SISPM1040-xxxx-L3 Web User Guide
33856 Rev. A https://www.lantronix.com/ 160
IGMP SSM Range: SSM (Source-Specific Multicast) Range allows the SSM-aware hosts and routers run the
SSM service model for the groups in the address range. Assign valid IPv4 multicast address as prefix with a prefix
length (from 4 to 32) for the range.
Leave Proxy Enabled: Enable IGMP Leave Proxy. This feature can be used to avoid forwarding unnecessary
leave messages to the router side.
Proxy Enabled: Enable IGMP Proxy to avoid forwarding unnecessary join and leave messages to the router side.
Port Configuration:
Router Port: Specify which ports act as router ports. A router port is a port on the Ethernet switch that leads
towards the Layer 3 multicast device or IGMP querier. If an aggregation member port is selected as a router port,
the whole aggregation will act as a router port.
Fast Leave: Enable the fast leave on the port. System will remove group record and stop forwarding data upon
receiving the leave message without sending last member query messages. It is recommended to enable this
feature only when a single IGMPv2 host is connected to the specific port.
Throttling: Enable to limit the number of multicast groups to which a switch port can belong.
Filtering Profile: Select the profile for this port. Click to preview the page which list the rules associated with the
selected profile.
Buttons
Apply: Click to save changes.
Reset: Click to undo any changes made locally and revert to previously saved values.
