Mirror: Specify the mirror operation of this port. Frames matching the ACE are mirrored to the destination mirror
port. The allowed values are:
Enabled: Frames received on the port are mirrored.
Disabled: Frames received on the port are not mirrored. The default value is "Disabled".
Counter: The counter indicates the number of times the ACE was hit by a frame.
Modification Buttons
You can modify each ACE (Access Control Entry) in the table using the following buttons:
: Inserts a new ACE before the current row.
: Edits the ACE row.
: Moves the ACE up the list.
: Moves the ACE down the list.
: Deletes the ACE.
: The lowest plus sign adds a new entry at the bottom of the ACE listings.
Buttons
Auto-refresh: Check this box to refresh the page automatically every 3 seconds.
Refresh: Click to refresh the page; any changes made locally will be undone.
Clear: Click to clear the counters.
Remove All: Click to remove all ACEs.
From the default page, click the Add ACE ( ) button to display the ACE Configuration page:
