SIP Filter: Specify the source IP filter for this ACE:
Any: No source IP filter is specified. (Source IP filter is "don't-care".)
Host: Source IP filter is set to Host. Specify the source IP address in the SIP Address field that appears.
Network: Source IP filter is set to Network. Specify the source IP address and source IP mask in the SIP
Address and SIP Mask fields that appear.
SIP Address: When "Host" or "Network" is selected for the source IP filter, you can enter a specific SIP address
in dotted decimal notation. Notice the invalid IP address configuration is acceptable too, for example, 0.0.0.0.
Normally, an ACE with invalid IP address will explicitly adding deny action.
SIP Mask: When "Network" is selected for the source IP filter, you can enter a specific SIP mask in dotted
decimal notation.
DIP Filter: Specify the destination IP filter for this ACE:
Any: No destination IP filter is specified. (Destination IP filter is "don't-care".)
Host: Destination IP filter is set to Host. Specify the destination IP address in the DIP Address field that
appears.
Network: Destination IP filter is set to Network. Specify the destination IP address and destination IP
mask in the DIP Address and DIP Mask fields that appear.
DIP Address: When "Host" or "Network" is selected for the destination IP filter, you can enter a specific DIP
address in dotted decimal notation. Notice the invalid IP address configuration is acceptable too, for example,
0.0.0.0. Normally, an ACE with invalid IP address will explicitly adding deny action.
DIP Mask: When "Network" is selected for the destination IP filter, you can enter a specific DIP mask in dotted
decimal notation.
IPv6 Parameters: The IPv6 parameters can be configured when Frame Type "IPv6" is selected.
Next Header Filter: Specify the IPv6 next header filter for this ACE.
Any: No IPv6 next header filter is specified ("don't-care").
Specific: If you want to filter a specific IPv6 next header filter with this ACE, choose this value. A field for
entering an IPv6 next header filter appears.
ICMP: Select ICMP to filter IPv6 ICMP protocol frames. Extra fields for defining ICMP parameters will
appear. These fields are explained later in this manual.
UDP: Select UDP to filter IPv6 UDP protocol frames. Extra fields for defining UDP parameters will appear.
These fields are explained later in this manual.
TCP: Select TCP to filter IPv6 TCP protocol frames. Extra fields for defining TCP parameters will appear.
These fields are explained later in this manual.
Next Header Value: When "Specific" is selected for the IPv6 next header value, you can enter a specific value.
The allowed range is 0 to 255. A frame that hits this ACE matches this IPv6 protocol value.
SIP Filter: Specify the source IPv6 filter for this ACE:
Any: No source IPv6 filter is specified. (Source IPv6 filter is "don't-care".)
Specific: Source IPv6 filter is set to Network. Specify the source IPv6 address and source IPv6 mask in
the SIP Address fields that appear.
SIP Address: When "Specific" is selected for the source IPv6 filter, you can enter a specific SIPv6 address. The
field only supported last 32 bits for IPv6 address.
SIP BitMask: When "Specific" is selected for the source IPv6 filter, you can enter a specific SIPv6 mask. The field
only supported last 32 bits for IPv6 address. Notice the usage of bitmask, if the binary bit value is "0", it means
this bit is "don't-care". The real matched pattern is [sipv6_address & sipv6_bitmask] (last 32 bits). For example, if
the SIPv6 address is 2001::3 and the SIPv6 bitmask is 0xFFFFFFFE(bit 0 is "don't-care" bit), then SIPv6 address
2001::2 and 2001::3 are applied to this rule.
