Lantronix SISPM1040-xxxx-L3 Web User Guide
33856 Rev. A https://www.lantronix.com/ 263
Hop Limit: Specify the hop limit settings for this ACE.
0: IPv6 frames with a hop limit field greater than zero must not be able to match this entry.
1: IPv6 frames with a hop limit field greater than zero must be able to match this entry.
Any: Any value is allowed ("don't-care").
ICMP Parameters:
ICMP Type Filter: Specify the ICMP filter for this ACE.
Any: No ICMP filter is specified (ICMP filter status is "don't-care").
Specific: If you want to filter a specific ICMP filter with this ACE, you can enter a specific ICMP value.
A field for entering an ICMP value appears.
ICMP Type Value: When "Specific" is selected for the ICMP filter, you can enter a specific ICMP value.
The allowed range is 0 to 255. A frame that hits this ACE matches this ICMP value.
ICMP Code Filter: Specify the ICMP code filter for this ACE.
Any: No ICMP code filter is specified (ICMP code filter status is "don't-care").
Specific: If you want to filter a specific ICMP code filter with this ACE, you can enter a specific ICMP
code value. A field for entering an ICMP code value appears.
ICMP Code Value: When "Specific" is selected for the ICMP code filter, you can enter a specific ICMP code
value. The allowed range is 0 to 255. A frame that hits this ACE matches this ICMP code value.
TCP/UDP Parameters
TCP/UDP Source Filter: Specify the TCP/UDP source filter for this ACE:
Any: No TCP/UDP source filter is specified (TCP/UDP source filter status is "don't-care").
Specific: If you want to filter a specific TCP/UDP source filter with this ACE, you can enter a specific
TCP/UDP source value. A field for entering a TCP/UDP source value appears.
Range: If you want to filter a specific TCP/UDP source range filter with this ACE, you can enter a specific
TCP/UDP source range value. A field for entering a TCP/UDP source value appears.
TCP/UDP Source No.: When "Specific" is selected for the TCP/UDP source filter, you can enter a specific
TCP/UDP source value. The allowed range is 0 to 65535. A frame that hits this ACE matches this TCP/UDP
source value.
TCP/UDP Source Range: When "Range" is selected for the TCP/UDP source filter, you can enter a specific
TCP/UDP source range value. The allowed range is 0 to 65535. A frame that hits this ACE matches this
TCP/UDP source value.
TCP/UDP Destination Filter: Specify the TCP/UDP destination filter for this ACE:
Any: No TCP/UDP destination filter is specified (TCP/UDP destination filter status is "don't-care").
Specific: If you want to filter a specific TCP/UDP destination filter with this ACE, you can enter a specific
TCP/UDP destination value. A field for entering a TCP/UDP destination value appears.
Range: If you want to filter a specific range TCP/UDP destination filter with this ACE, you can enter a
specific TCP/UDP destination range value. A field for entering a TCP/UDP destination value appears.
TCP/UDP Destination Number: When "Specific" is selected for the TCP/UDP destination filter, you can enter a
specific TCP/UDP destination value. The allowed range is 0 to 65535. A frame that hits this ACE matches this
TCP/UDP destination value.
TCP/UDP Destination Range: When "Range" is selected for the TCP/UDP destination filter, you can enter a
specific TCP/UDP destination range value. The allowed range is 0 to 65535. A frame that hits this ACE matches
this TCP/UDP destination value.
