Port: The port ID which wants to be monitored.
Drop: The total number of events in which packets were dropped by the probe due to lack of resources.
Octets: The total number of octets of data (including those in bad packets) received on the network.
Pkts: The total number of packets (including bad packets, broadcast packets, and multicast packets) received.
Broadcast: The total number of good packets received that were directed to the broadcast address.
Multicast: The total number of good packets received that were directed to a multicast address.
CRC/Alignment: The total number of packets received that had a length (excluding framing bits but including
FCS octets) of between 64 and 1518 octets, inclusive, but had either a bad Frame Check Sequence (FCS) with
an integral number of octets (FCS Error) or a bad FCS with a non-integral number of octets (Alignment Error).
Undersize: The total number of packets received that were less than 64 octets.
Oversize: The total number of packets received that were longer than 1518 octets.
Fragment: The number of frames which size is less than 64 octets received with invalid CRC.
Jabber: The number of frames which size is larger than 64 octets received with invalid CRC.
Collisions: The best estimate of the total number of collisions on this Ethernet segment.
64: The total number of packets (including bad packets) received that were 64 octets in length.
65~127: The total number of packets (including bad packets) received that were between 65 to 127 octets in
length.
128~255: The total number of packets (including bad packets) received that were between 128 to 255 octets in
length.
256~511: The total number of packets (including bad packets) received that were between 256 to 511 octets in
length.
512~1023: The total number of packets (including bad packets) received that were between 512 to 1023 octets in
length.
1024~1588: The total number of packets (including bad packets) received that were between 1024 to 1588 octets
in length.
Buttons
Auto-refresh: Check this box to refresh the page automatically every 3 seconds.
Refresh: Click to refresh the page immediately.
ID Select box: At the dropdown select the desired instance number.
