Lantronix SISPM1040-xxxx-L3 Web User Guide
33856 Rev. A https://www.lantronix.com/ 293
Alarm Control: Level: If a defect is detected with a priority higher than this level, a fault alarm notification will be
generated. Valid range is [1; 6] with 1 indicating that any defect will cause a fault alarm and 6 indicating that no
defect can cause a fault alarm. See 802.1Q-2018, clause 20.9.5, LowestAlarmPri.
The possible defects and their priorities are:
Short name Description Priority
DefRDICCM Remote Defect Indication 1
DefMACstatus MAC Status 2
DefRemoteCCM Remote CCM 3
DefErrorCCM Error CCM Received 4
DefXconCCM Cross Connect CCM Received 5
Present: The time in milliseconds that defects must be present before a fault alarm notification is issued. Default
is 2500 ms.
Absent: The time in milliseconds that defects must be absent before a fault alarm notification is reset. Default is
10000 ms.
State Control: Check or uncheck these checkboxes:
CCM: Enable or disable generation of continuity-check messages (CCMs).
Admin: Enable or disable this MEP. When this MEP is enabled, it will check received/missing CCMs and
can raise defects.
Remote MEPID: Specify the Remote MEP that this MEP is expected to receive CCM PDUs from. Must be an
integer [0..8091] where 0 means undefined. The value of Remote MEPID must be different from the value of
MEPID.
Buttons
Auto-refresh: Check this box to refresh the page automatically every 3 seconds.
Refresh: Click to refresh the page immediately.
Add New Entry: Click to add a new MEP entry.
Apply: Click to save changes.
Reset: Click to undo any changes made locally and revert to previously saved values.
Messages:
AlarmPresentMs must be an integer value between 2500 and 10000
JSON RPC Error. (A Remote MEP-ID cannot be identical to this MEP's MEP-ID)
JSON RPC Error. (There can only be one Port MEP per interface, and another Port MEP already exists on this
one)
MAC address must be 12 characters long
JSON RPC Error. (Invalid params)
