Trap Security Engine ID: Indicates the SNMP trap security engine ID. SNMPv3 sends traps and informs using
USM for authentication and privacy. A unique engine ID for these traps and informs is needed. When "Trap Probe
Security Engine ID" is enabled, the ID will be probed automatically. Otherwise, the ID specified in this field is
used. The string must contain an even number (in hexadecimal format) with the number of digits between 10 and
64, but all-zeros and all-'Fs are not allowed.
Trap Security Name: Indicates the SNMP trap security name. SNMPv3 traps and informs using USM for
authentication and privacy. A unique security name is needed when traps and informs are enabled.
Buttons
Apply: Click to save changes.
Reset: Click to undo any changes made locally and revert to previously saved values.
Example:
Name: Displays the trap Configuration's name (e.g., the trap destination's name). Click a linked name to display
the related SNMP Trap Configuration page where you can make further trap parameter edits.
Mode: Displays the trap destination mode operation. Possible modes are:
TCP: TCP SNMP trap mode operation is enabled.
UDP: UDP SNMP trap mode operation is enabled.
Disabled: Disable SNMP trap mode operation is disabled.
Version: Indicates the SNMP trap supported version. Possible versions are:
SNMPv1: SNMP trap version 1 is configured.
SNMPv2c: SNMP trap version 2c is configured.
SNMPv3: SNMP trap version 3 is configured.
Destination Address: Displays the SNMP trap destination address. It shows a valid IP address in dotted decimal
notation ('x.y.z.w'). It may also display a valid hostname. A valid hostname is a string drawn from the alphabet (A-
Za-z), digits (0-9), dot (.), dash (-). Spaces are not allowed, the first character must be an alpha character, and the
first and last characters must not be a dot or a dash.
It may also display the SNMP trap destination IPv6 address. IPv6 address is in 128-bit records represented as
eight fields of up to four hexadecimal digits with a colon separating each field (:). For example,
'fe80::215:c5ff:fe03:4dc7'. The symbol '::' is a special syntax that can be used as a shorthand way of representing
multiple 16-bit groups of contiguous zeros; but it can appear only once. It can also represent a valid IPv4 address
(for example, '::192.1.2.34').
Destination Port: Displays the SNMP trap destination port. The SNMP Agent will send SNMP messages via this
port. The port range is 1~65535.
