Multiplexer State: When in forwarding state, the Device is forwarding non-OAMPDUs to the lower sublayer. In
case of discarding, the device discards all the non-OAMPDU's.
Parser State: When in forwarding state, Device is forwarding non-OAMPDUs to higher sublayer. When in
loopback, Device is looping back non-OAMPDUs to the lower sublayer. When in discarding state, Device is
discarding non-OAMPDUs.
Organizational Unique Identification: 24-bit Organizationally Unique Identifier of the vendor.
PDU Revision: It indicates the current revision of the Information TLV. The value of this field shall start at zero
and be incremented each time something in the Information TLV changes. Upon reception of an Information TLV
from a peer, an OAM client may use this field to decide if it needs to be processed (an Information TLV that is
identical to the previous Information TLV doesn't need to be parsed as nothing in it has changed).
PDU Permission: This field is available only for the Local DTE. It displays the current permission rules set for the
local DTE. Possible values are "Link fault”, “Receive only", "Information exchange only" and "ANY".
Discovery State: Displays the current state of the discovery process. Possible states are Fault state, Active state,
Passive state, SEND_LOCAL_REMOTE_STATE, SEND_LOCAL_REMOTE_OK_STATE, SEND_ANY_STATE.
Buttons
: The port select box determines which port is affected by clicking the buttons.
Auto-refresh: Check this box to enable an automatic refresh every 3 seconds.
Refresh: Click to refresh the page immediately.
