214603 81 Revision A
Display (Lower or Upper Line)
Description
##.# SWATH COMPR HT
SWATH CO SENSOR
Swath compressor height (00.0–10.0); fully raised is 0
Sensor disabled
SCROLL
SUB-MENU (lower line only)
#### KNIFE SPEED
##.# HEADER HEIGHT
LOAD|■■■■|■■■■| ####
Displays sub-menu after 2 to 3 seconds. Press SELECT to
cancel. Scroll through sub-menu display with CDM switch
Cab-Forward, Engine Running, Header Engaged, Auger Header Index Switch ON
Scroll through display with cab display module (CDM) switch or ground speed lever (GSL) switch.
Display (Lower or Upper Line)
Description
#####.# ENGINE HRS
Total engine operating time
#####.# UNIT HRS
Total windrower operating time
#####.# HEADER HRS
Total header operating time
##.# ACRES/HOUR
##.# HECTARES/HOUR (if metric)
Actual cutting rate in acres (hectares)/hour
###.# SUB ACRES
###.# SUB HECTARES (if metric)
Area cut since last reset; to reset, display SUB ACRES on
lower line, and hold down PROGRAM switch until display
resets 5 to 7 seconds)
###### TOTAL ACRES
###### TOTAL HECT (if metric)
Total area cut by machine
##.## ##.# REEL IND.
##.## REEL SENSOR
Reel peripheral speed along with ground speed in mph
or km/h
Sensor disabled. IND and SENSOR alternate at 1 second
intervals
##.# AUGER SPEED
##.# AUGER SENSOR
Auger rotational speed (4.7–9.9)
Sensor disabled. SPEED and SENSOR alternate at
1 second intervals
#### KNIFE SPEED
#### KNIFE SENSOR
Knife speed In strokes per minute
Sensor disabled. SPEED and SENSOR alternate at
1 second intervals
##.# HEADER HEIGHT
##.# HEADER SENSOR
Distance setting (00.0–10.0) between cutterbar and ground
Sensor disabled. HEIGHT and SENSOR alternate at
1 second intervals
##.# HEADER ANGLE
##.# TILT SENSOR
Angle setting (00.0–10.0) header relative to ground.
Sensor disabled. ANGLE and SENSOR alternate at
1 second intervals
##.# L FLOAT R ##.#
FLOAT SENS DISABLED (if sensor disabled)
Left and right float setting (0.0–10.0)
Sensor disabled
OPERATOR’S STATION
