MacDon M205 - Symbol Definitions

214603 158 Revision A
4.2 Symbol Definitions
The following symbols are used to depict functions or reactions of the various instruments and controls.
Learn the meaning of these symbols before operating the windrower.
4.2.1 Engine Functions
These are the symbols that are used on the console.
Figure 4.1: Engine Function Symbols
1000659
A
B
C
D
E
F
G
H
J
K
L
M
N
A - Electrical Power – Accessories B - Engine Coolant Temperature C - Engine Glow Plugs
D - Engine Malfunction E - Engine rpm F - Engine Run
G - Engine Start H - Engine Stop J - Engine Throttle
K - Engine Urgent Stop L - Fast M - Slow
N - Water in Fuel
