214603 79 Revision A
Engine-Forward, Engine Running
Display Description
ROAD GEAR (upper line) low-speed range in HIGH range
#####.# ENGINE HRS (upper or lower line)
Total engine operating time
#####.# UNIT HRS (upper or lower line)
Total windrower operating time
#####.# HEADER HRS (upper or lower line)
Total header operating time
###### TOTAL ACRES (upper or lower line)
###### TOTAL HECT (if metric)
Total area cut by machine
##.# HEADER HEIGHT (upper or lower line) Distance setting (00.0–10.0) between cutterbar and ground
##.# HEADER ANGLE (upper or lower line) Angle setting (00.0–10.0) header relative to ground
### °C or F HYD OIL TEMP
Hydraulic oil temperature
##.# VOLTS (upper or lower line)
Engine electrical system operating voltage
##.# SWATH COMPR HT Swath compressor height (00.0–10.0); fully raised is 0.
SCROLL (lower line)
Displays above items after 2 to 3 seconds; press SELECT
to cancel
Cab-Forward, Engine Running, Header Disengaged
Scroll through display with cab display module (CDM) switch or ground speed lever (GSL) switch.
Display (Lower or Upper Line) Description
#####.# ENGINE HRS
Total engine operating time
#####.# UNIT HRS
Total windrower operating time
#####.# HEADER HRS
Total header operating time
###.# SUB ACRES
###.# SUB HECTARES (if metric)
Area cut since last reset. To reset, display SUB ACRES on lower line,
and hold down PROGRAM switch until display resets (five to seven
seconds)
###### TOTAL ACRES
###### TOTAL HECT (if metric)
Total area cut by machine
##.# HEADER HEIGHT Distance setting (00.0–10.0) between cutterbar and ground
##.# HEADER ANGLE Angle setting (00.0–10.0) header relative to ground
##.# L FLOAT R ##.# Float setting (0.0–10.0)
### °C or F HYD OIL TEMP
Hydraulic oil temperature
##.# VOLTS
Engine electrical system operating voltage
##.# SWATH COMPR HT Swath compressor height (00.0–10.0); fully raised is 0.
SCROLL (lower line)
Displays above items after two to three seconds; press SELECT to
cancel
OPERATOR’S STATION
