5.3 Maintenance Platforms
Swing-away platforms and stairs are provided on both sides of the windrower for access to the operator’s station
and engine bay. The platforms can be swung away from the windrower to allow access to the hydraulics plumbing
or battery.
The maintenance platforms have three positions:
• Closed position
• Open standard position
• Open major servicing position
5.3.1 Opening Platforms (Standard Position)
CAUTION
Do NOT stand on an unlocked platform. It is unstable and may cause you to fall.
1006274
A
B
Figure 5.5: Platforms
This procedure describes how to open the cab-forward left
platform (A). The same procedure is used for the right
platform (B).
