MacDon M205 - Air Precleaner; Fuel System; Replacing Fuel Tank Vent Filter

214603 323 Revision A
1007893
A
Figure 5.64: Secondary Filter Element
2. Remove secondary element (A) from canister.
3. Insert new secondary filter element (A) into canister,
seal first, and push until seal is seated inside canister.
4. Reinstall the primary filter. Refer to Installing Primary Air
Filter, page 320.
Air Precleaner
1022595
A
Figure 5.65: Engine Air Precleaner
The engine air precleaner (A) is attached to the engine
compartment hood, and in the closed position, it is sealed to
the engine air intake duct in the engine compartment. There
are no scheduled servicing requirements other than to
ensure the intake is not blocked.
5.8.5 Fuel System
Replacing Fuel Tank Vent Filter
The fuel tank is vented by a hose that is connected to the filler tube. The hose is connected to a filter that should be
changed every year.
For fuel tank vent filter replacement part number, refer to 8.2.4 Filter Part Numbers, page 462.
DANGER
To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and
remove the key from the ignition before leaving the operator’s seat for any reason.
WARNING
To avoid personal injury or death from explosion or fire, do NOT smoke or allow flame or sparks near
windrower when servicing.
MAINTENANCE AND SERVICING
