MacDon M205 - Interior Lights

214603 60 Revision A
3.11 Interior Lights
1013881
A
B
Figure 3.38: Interior Lights
Two interior lights are installed in the cab headliner.
A low intensity LED light (A) is located directly overhead to
provide ambient lighting if desired. It functions only when
the key is in the RUN position. An ON/OFF switch is located
on the light.
The other interior light (B) is located on the headliner switch
panel and the push-ON, push-OFF button is located on
the light. It functions at any time.
OPERATOR’S STATION
