3.3.3 Adjusting Vertical Dampener
Controls suspension dampening.
1000579
A
Figure 3.6: Vertical Dampener
INCREASE: Turn knob (A) counterclockwise.
DECREASE: Turn knob (A) clockwise.
3.3.4 Adjusting the Armrest
1000575
A
Figure 3.7: Armrest
Raise armrest (A) for easier access to seat.
Lower armrest (A) after seat belt is buckled.
