214603 66 Revision A
3.15 Horn
Figure 3.50: Horn Button Location
The horn is activated by pushing button (A) located on the
panel in the headliner.
Sound the horn three times prior to starting the engine.
Figure 3.51: Horn Location
The horn (A) is located outside the cab on the rear right
cab-forward corner of the cab, under the roof.
OPERATOR’S STATION
