214603 167 Revision A
Figure 4.11: Operator Console
1. Lower header.
2. Place ground speed lever (GSL) (B) into N-DETENT.
3. Lock steering wheel.
4. Turn ignition key (A) counterclockwise to OFF position.
Filling the Fuel Tank
Fill the fuel tank daily, preferably at the end of the day’s operation to help prevent condensation in the tank.
DANGER
To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and
remove the key from the ignition before leaving the operator’s seat for any reason.
WARNING
• To avoid personal injury or death from explosion or fire, do NOT smoke or allow flame or sparks near
fuel tank when refueling.
• NEVER refuel the windrower when the engine is hot or running.
CAUTION
Do NOT allow tank to empty. Running out of fuel can cause air locks and/or contamination of the fuel
system. Refer to System Priming, page 330.
1. Stop windrower and remove key.
2. Stand on either platform to access the fuel tank filler pipe.
OPERATION
