MacDon M205 - Component Location

214603 37 Revision A
2.4 Component Location
Figure 2.4: Front Cab-Forward View
1022542
A
B
C
D
E
F
G
H
F
K
L
M
N
J
J
A - Header Lift Leg B - Header Float Springs C - Operator’s Station
D - Windshield Wiper E - Turn Signal/Hazard Lights F - Taillight Engine-Forward
G - Field/Road Lights H - Handholds J - Beacon
K - Mirror L - Door M - Maintenance Platform
N - Center-Link
PRODUCT OVERVIEW
