8.2.3 Lubricants, Fluids, and System Capacities
CAUTION
To avoid injury or death, do not allow ANY machine fluids to enter the body.
Table 8.16 System Capacities
Lubricant/Fluid
Location Description
Capacity
Grease
As required unless
otherwise specified
SAE multi-purpose high temperature
extreme pressure (EP2) performance
with 1% max Molybdenum Disulphide
(NLGI Grade 2) lithium base
—
Diesel fuel
Fuel tank
Diesel Grade No. 2, or Diesel Grade
No. 1 and 2 mix
51
; refer to 8.2.2 Fuel
Specifications, page 460 for more
information
378 liters
(97 US gallons)
Hydraulic oil Hydraulic reservoir
SAE 15W-40 compliant with SAE specs
for API class SJ and CH-4 engine oil
65 liters
(17.2 US gallons)
Gear lubricant Gearbox
SAE 80W-140, API service class GL-5
Fully synthetic gear lubricant,
(SAE J2360 preferred)
2.1 liters
(2.2 US quarts)
Gear lubricant
Wheel drive
52
SAE 75W-90, API service class GL-5
Fully synthetic gear lubricant,
(SAE J2360 preferred)
1.4 liters
(1.5 US quarts)
Antifreeze
Engine cooling
system
ASTM D-6210 and Fleetguard ES
Compleat
®
.
See notes at the end of this table
31 liters
(8.2 US gallons)
53
Engine oil Engine oil pan
SAE 15W-40 compliant with SAE specs
for API class SJ and CH-4 engine oil
14.2 liters
(15.0 US quarts)
Air conditioning
refrigerant
Air conditioning
system
R134A
2.27 kg (5 lb.)
Air conditioning
refrigerant oil
54
Air conditioning
system total
capacity
PAG SP-15 240 cc (8.1 fl. oz.)
REFERENCE
51. Optional when operating temperature is below 0°C (32°F).
52. SAE 85W-140 API Service Class GL-5 Extreme Pressure Gear Lubricant is used before initial change.
53. Equal parts with water, high quality, soft, de-ionized or distilled water as recommended by supplier.
54. New compressor (MD #203013) comes filled. If installing on 2014 and prior models, refer to Service
Bulletin 1254.
