3.13 Operator Amenities
The operator’s station includes the following amenities:
10006011000601
A
B
C
D
E
Figure 3.41: Console
Operator’s Console
A - Auxiliary power outlet
B - Utility tray (under armrest)
C - Cigarette lighter
D - Ashtray/cup holder
E - Utility tray
1000602
A
A
Figure 3.42: Windshield Shades
Windshield Shades (Optional)
Retractable window shades (A) can be installed for the front
and rear windows. Refer to 7.1.7 Windshield Shades, page
444 for ordering information.
1010329
A
B
C
D
E
Figure 3.43: Auxiliary Power Outlets
A - Auxiliary Power Outlet B - Auxiliary Power Outlet
C - Battery Terminal D - Ground Terminal
E - Switched Terminal
Auxiliary Outlets
Two auxiliary power outlets are located on either side of the
wiper motor cover/storage tray behind the Operator
(cab-forward mode).
