5.4.2 Lubrication Points
Figure 5.15: Lubrication Points
1008966
E
B
A
C
D
E
A
A - Forked Caster Wheel Bearing (Two Places) (Outer – Both Wheels)
B - Top-Link (Two Places) (Both Sides)
C - Lubrication Decal (MD #183411)
D - Caster Pivot (Both Sides)
E - Forked/Formed Caster Wheel Bearing (Two Places) (Inner – Both Wheels) (50 Hrs/250 Hrs)
