MacDon M205 - Cleaning Return Air Cleaner;Filter

214603 306 Revision A
1000131
A
B
Figure 5.34: Return Air Filter
2. Separate the filter (B) from the cover (A).
3. Clean or replace the filter. If cleaning filter, refer to
Cleaning Return Air Cleaner/Filter, page 306.
4. Assemble the cleaner (B) and cover (A), and position
on cab wall over opening.
1000132
A
B
Figure 5.35: Return Air Filter
5. Secure filter assembly (B) to cab wall with knobs (A).
Cleaning Return Air Cleaner/Filter
Clean the electrostatic filter as follows:
1020943
A
Figure 5.36: Return Air Filter
1. Mix a solution of warm water and detergent in a suitable
container and soak the filter (A) for a few minutes.
2. Agitate to flush out the dirt.
3. Rinse with clean water, and then dry with
compressed air.
4. Inspect filter for damage, separation, and holes.
Replace if damaged.
MAINTENANCE AND SERVICING
