MacDon M205 - Cab-Forward, Engine Running, Header Engaged, Draper Header Index Switch on

214603 83 Revision A
Display (Lower or Upper Line)
Description
##.# L FLOAT R ##.#
FLOAT SENS DISABLED
Left and right float setting (0.0–10.0)
Sensor disabled
### °C or F HYD OIL TEMP
### °C or F HYD SENSOR
Hydraulic oil temperature
Sensor disabled. TEMP and SENSOR alternate at 1 second intervals
LOAD|■■■■| | ####
Bar graph representing hydraulic operating pressure. Full scale is pre-
programmed overload pressure (2500–5000 psi). If sensor disabled,
LOAD does not display
8
##.# VOLTS
Engine electrical system operating voltage
##.# SWATH COMPR HT
SWATH CO SENSOR
Swath compressor height (00.0–10.0); fully raised is 0
Sensor disabled
SCROLL
SUB-MENU (lower line only)
#### KNIFE SPEED
##.# HEADER HEIGHT
LOAD|■■■■|■■■■| ####
##.## REEL MPH
##.# DRAPER SPEED
Displays sub-menu after 2 to 3 seconds. Press SELECT to cancel.
Scroll through sub-menu display with CDM switch
KNIFE SPD OVERLOAD
Knife or disc speed drops below programmed value
Cab-Forward, Engine Running, Header Engaged, Draper Header Index Switch ON
Scroll through display with cab display module (CDM) switch or ground speed lever (GSL) switch.
Display (Lower or Upper Line)
Description
#####.# ENGINE HRS
Total engine operating time
#####.# UNIT HRS
Total windrower operating time
#####.# HEADER HRS
Total header operating time
##.# ACRES/HOUR
##.# HECTARES/HOUR (if metric)
Actual cutting rate in acres (hectares)/hour
###.# SUB ACRES
###.# SUB HECTARES (if metric)
Area cut since last reset. To reset, display SUB ACRES on lower line
and hold down PROGRAM switch until display resets (5 to 7 seconds)
###### TOTAL ACRES
###### TOTAL HECT (if metric)
Total area cut by machine
##.## ##.# REEL IND
REEL.SENSOR
Reel peripheral speed along with ground speed in mph or km/h
Sensor disabled. IND and SENSOR alternate at 1 second intervals
##.# ##.# DRAP INDX Draper speed along with ground speed in mph or km/h
#### KNIFE SPEED
#### KNIFE SENSOR
Knife speed in strokes per minute. Sensor disabled
SPEED and SENSOR alternate at 1 second intervals
##.# HEADER HEIGHT
##.# HEADER SENSOR
Distance setting (00.0–10.0) between cutterbar and ground
Sensor disabled. HEIGHT and SENSOR alternate at 1 second intervals
OPERATOR’S STATION
8. The LOAD sensor to monitor knife/conditioner circuit pressure is optional. To monitor reel/auger circuit
pressure, relocate sensor as per kit instruction MD #169031, which is available through your Dealer.
