MacDon M205 - Driving Reverse in Cab-Forward Mode

214603 173 Revision A
Driving Reverse in Cab-Forward Mode
WARNING
Back up slowly. Steering is opposite to normal when reversing. Hold steering wheel at the bottom and turn
wheel in direction you want the rear (cab-forward) of the machine to travel.
1005501
A
B
Figure 4.18: Operator’s Console
1. Set GROUND SPEED RANGE switch (A) to 1 (field
speed).
2. Move SPEED RANGE switch (A) to L (low-range
position).
3. Move throttle lever (B) to a mid-range position.
NOTE:
Steering will be less sensitive in low-speed range;
reduced engine speed.
CAUTION
Check again to be sure all bystanders have cleared
the area.
4. Move the ground speed lever (GSL) rearward to desired
speed.
1000672
Figure 4.19: Cab-Forward Mode
5. Steer as shown.
OPERATION
