MacDon M205 - Installing Air Conditioning (A;C) Cover

214603 309 Revision A
Installing Air Conditioning (A/C) Cover
1008547
A
B
Figure 5.41: A/C Cover
1. Straighten any bent fins.
2. Position cover (B) onto A/C unit, and attach with eight
screws (A).
1008578
A
Figure 5.42: A/C Cover
3. Reattach drain hoses to drain tubes and secure with
hose clamps (A).
MAINTENANCE AND SERVICING
