4.7 Operating with an A Series Header
1005502
Figure 4.234: Hydraulic Connections
To operate with an auger header, the M205 requires an
auger drive basic kit and a completion kit as shown. If
necessary, obtain the following kits from your MacDon
Dealer, and install them in accordance with the instructions
supplied with the kits.
Kit Description Kit Number
Base draper/auger drive kit MD #B5491
Draper conditioner/auger header
reverser completion kit
MD #B5492
Hydraulic coupler kit
MD #B5497
Hydraulic union kit
MD #166844
