Engine Warm-Up
Figure 4.10: Operator Console
Allow engine to run with throttle lever (A) at or near low-idle
position until temperature gauge (B) reaches approximately
40°C (100°F ).
NOTE:
Scroll through cab display module (CDM) for engine
temperature. Refer to Engine Temperature, page 168.
Engine Intermediate Speed Control (ISC)
The engine operating speed can be programmed to enable the windrower to operate at reduced engine rpm, that
is, 1600, 1800, 2000 rpm, or OFF (full throttle) without significantly affecting the ground or header speeds.
Engine ISC is useful when operating loads are reduced such as in light crop conditions that do not require the
maximum engine rpm. Reduced engine speed lowers fuel consumption, noise levels, and exhaust emissions in
addition to reducing engine wear.
The programmed engine speed is activated when the header is engaged.
Programming instructions are provided in 3.19.6 Cab Display Module (CDM) Configuration, page 90.
Shutting down the Engine
CAUTION
Park on a flat, level surface with the header on the ground and the ground speed lever in N-DETENT
position with the steering wheel locked.
IMPORTANT:
Before stopping engine, run at low idle for approximately 5 minutes to cool hot engine parts (and allow turbocharger
to slow down while engine oil pressure is available).
