5.12 Maintenance Schedule
The Maintenance Schedule specifies the recommended periodic maintenance procedures and service intervals.
Regular maintenance is the best insurance against early wear and untimely breakdowns. Follow this schedule to
maximize machine life.
For detailed instructions, refer to the various procedures in this chapter. Use the fluids and lubricants specified in
8.2 Recommended Fuel, Fluids, and Lubricants, page 460.
Service Intervals: The recommended service intervals are in hours of operation. Where a service interval is given
in more than one time frame, for example 100 hours or annually, service the machine at whichever interval is
reached first.
IMPORTANT:
Recommended intervals are for average conditions. Service the machine more often if operated under adverse
conditions (severe dust, extra heavy loads, etc.).
CAUTION
Carefully follow safety messages given in 1 Safety, page 1.
5.12.1 Maintenance Schedule/Record
Windrower Serial Number: ___________________
Combine this record with the record in the header operator ’s manual. Make copies of this page to continue the
record.
Action: üü Check SS Lubricate ▲ Change ®® Clean
!
Hour meter reading
!
Service date
!
Serviced by
Preseason or Annual. Refer to 4.3.3 Preseason Checks / Annual Service, page 162.
First hour
32
ü
Drive wheel nuts
Refer to Tightening Drive Wheel Nuts, page 400.
First 5 hours
32
ü
A/C compressor belt
Refer to Tensioning Air Conditioner (A/C) Compressor Belt, page 347.
ü
Caster wheel nuts
Refer to Tightening Caster Wheel Nuts, page 407.
ü
Caster wheel anti-shimmy dampener
bolts. Refer to Tightening Caster Wheel Anti-Shimmy Dampeners, page 413.
ü
Walking beam width adjustment bolts
MAINTENANCE AND SERVICING
32. Begins from first use of machine.
