4.5.5 Detaching an A Series Header
Detaching an A Series Header: Hydraulic Center-Link
DANGER
To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and
remove the key from the ignition before leaving the operator’s seat for any reason.
1008946
A
Figure 4.172: Ground Speed Lever
1. Start the engine and press HEADER UP switch (A) on
the ground speed lever (GSL) to raise the header to
maximum height.
2. If one end of the header does NOT raise fully, rephase
the cylinders as follows:
a. Press and hold the HEADER UP switch (A) until
both cylinders stop moving.
b. Continue to hold the switch for 3–4 seconds.
Cylinders are now phased.
3. Stop the engine and remove the key.
DANGER
To avoid bodily injury from fall of raised header, always engage safety props when working on or
around raised header, and before going under header for any reason.
