214603 243 Revision A
Figure 4.169: Safety Prop Lever
18. Disengage the safety prop by turning lever (A)
downwards until lever locks into vertical position.
19. Repeat for opposite safety prop.
Figure 4.170: Ground Speed Lever
CAUTION
Check to be sure all bystanders have cleared the area.
20. Start the engine and press HEADER DOWN switch (A)
on the GSL to fully lower the header.
21. Stop engine and remove key from ignition.
Figure 4.171: Header Drive Hoses and Harness
22. Connect header drive hoses (A) and electrical
harness (B) to header. Refer to the draper header
operator’s manual.
OPERATION
