4.4.10 Using the Double Windrowing Attachment
The double windrow attachment (DWA) deposits two windrows of conditioned material close together to be picked
up by a forage chopper.
Figure 4.92: DWA on SP Windrower
1. The system is for use with the A Series Auger Headers
and R Series Rotary Disc Headers.
Raising the side delivery system shuts off the draper
and allows the crop to be deposited between the
windrower wheels as it would be without the side
delivery system.
Refer to MacDon M Series Windrower Double Windrow
Attachment Manual for complete operating and
maintenance instructions. The manual is shipped with
the DWA kit.
Figure 4.93: Double Windrowing
2. The conditioned crop is deposited onto the side delivery
system draper and delivered to the side of the
windrower when required. Cutting up and down shown.
