3.9 Rear View Mirrors
1000595
A
B
Figure 3.34: Mirrors
Two outside-mounted, adjustable mirrors (A) provide a rear
view when the windrower is in cab-forward mode.
A single interior-mounted mirror (B) provides a rear view in
the engine-forward mode.
The mirror/light assembly (A) is designed to fold back if
accidentally struck. A detent-type lock keeps it in place.
