MacDon M205 - Cab-Forward, Engine Running, Header Engaged, Draper Header, Index Switch off

214603 82 Revision A
Display (Lower or Upper Line)
Description
LOAD|■■■■| | ####
Bar graph representing hydraulic operating pressure. Full
scale is preprogrammed overload pressure (2500–
5000 psi). If sensor disabled, LOAD does not display
7
### °C or F HYD OIL TEMP
### °C or F HYD TEMP
Hydraulic oil temperature
Sensor disabled. TEMP and SENSOR alternate at
1 second intervals
##.# VOLTS
Engine electrical system operating voltage
##.# SWATH COMPR HT
SWATH CO SENSOR
Swath compressor height (00.0–10.0); fully raised is 0
Sensor disabled
SCROLL
SUB-MENU (lower line only)
#### KNIFE SPEED
##.# HEADER HEIGHT
LOAD|■■■■|■■■■| ####
Displays sub-menu after two to three seconds. Press
SELECT to cancel. Scroll through sub-menu display with
CDM switch
Cab-Forward, Engine Running, Header Engaged, Draper Header, Index Switch OFF
Scroll through display with cab display module (CDM) switch or ground speed lever (GSL) switch.
Display (Lower or Upper Line)
Description
#####.# ENGINE HRS
Total engine operating time
#####.# UNIT HRS
Total windrower operating time
#####.# HEADER HRS
Total header operating time
##.# ACRES/HOUR
##.# HECTARES/HOUR (if metric)
Actual cutting rate in acres (hectares)/hour
###.# SUB ACRES
###.# SUB HECTARES (if metric)
Area cut since last reset. To reset, display SUB ACRES on lower line,
and hold down PROGRAM switch until display resets (5 to 7 seconds)
###### TOTAL ACRES
###### TOTAL HECT (if metric)
Total area cut by machine
##.## REEL MPH
##.## REEL KPH (if metric)
##.## REEL SENSOR (flashing)
Reel peripheral speed
Sensor disabled. MPH or KPH and SENSOR alternate at 1 second
intervals
##.# DRAPER SPEED Draper speed (0.0–11.0)
#### KNIFE SPEED
#### KNIFE SENSOR
Knife speed In strokes per minute
Sensor disabled. SPEED and SENSOR alternate at 1 second intervals
##.# HEADER HEIGHT
##.# HEADER SENSOR
Distance setting (00.0–10.0) between cutterbar and ground
Sensor disabled. HEIGHT and SENSOR alternate at 1 second intervals
##.# HEADER ANGLE
##.# HEADER SENSOR
Angle setting (00.0–10.0). Header relative to ground
Sensor disabled. ANGLE and SENSOR alternate at 1 second intervals
OPERATOR’S STATION
7. The LOAD sensor to monitor knife/conditioner circuit pressure is optional. To monitor reel/auger circuit
pressure, relocate sensor as per kit instruction MD #169031, which is available through your Dealer.
