214603 260 Revision A
3. Stop engine and remove key from ignition.
1000770
A
B
Figure 4.211: Safety Prop
4. Pull lever (A) and rotate toward header to lower safety
prop (B) onto cylinder. Repeat for opposite cylinder.
1000812
A
B
C
Figure 4.212: Header Boots
5. Remove hairpin from clevis pin (A) and remove clevis
pin from header boot (B) on both sides of header.
OPERATION
