214603 390 Revision A
Figure 5.187: Return Oil Filter
3. Locate return filter (A) next to the manifold.
4. Clean around head filter (A).
5. Place a container beneath filter (A) to collect any oil that
may leak out.
6. Unscrew filter (A) with a filter wrench.
7. Dispose of used oil and filter in accordance with local
legislation.
Figure 5.188: Return Oil Filter
NOTE:
Filter head removed to show component clarity.
8. Remove gasket (C) from groove (B) in filter head (A).
Filter (D) shown for context.
MAINTENANCE AND SERVICING
